PNC EDM Die Sinking Machine
Contact UsPositive and Negative coordinate processing.
With W axis for moving machine head to load high product
Programmable Z axis, 10 step, 99 program storage
Built in 3 axis Linear scale ( 1um or 5um)
Precision co-ordinate table on flat & V type turcide coated guide ways driven by ball screw
Double door and large working tank for ease of loading & unloading of workpiece
Oil level alarm, insufficient liquid level protection;
With the quill running on preloaded cross roller bearing and ball screw for accuracyworking
High speed quill moment with Panasonic AC servo motor, more efficient than DC servo motor.
New generation superfine discharge ciruit for mirror surface
Hand held multi-function remote controller
Reverse servo machining
Automatic carbon deposition detection function, adjusts various processing parameters automatically
Special circuits for deep hole and large area electrode processing
Self-diagnostic trouble shooting with alarm
Automatic lubrication system
Fire extinguisher, Smoke detector alarm
Power efficient high pressure dielectric pump -
Pneumatic Angle Seat Valve
Contact UsValve body: CF8, CF8M, SS316L, 2205
Actuator: stainless steel
Seat sealing: PTFE, RPTFE, PEEK
Valve stem seal: PTFE, FKM, RPTFE
Piston seal: FKM, NBR
Nominal pressure (working pressure): 0-16bar (0-232Psi), optional vacuum as low as -0.9bar
Control pressure: 2-10bar
Control medium: clean compressed air, neutral gas, temperature: ≤ 60 ℃
External temperature (environment): -10 ℃~+80 ℃
Applicable media: water, neutral gases or liquids, alcohol, oil, fuel, steam, organic solvents, acid-base solutions, etc
Medium temperature: -10 ℃~+180 ℃ (PTFE room temperature type)
+25 ℃~+220 ℃ (PTFE high-temperature type)
Maximum viscosity: 600cst (mm2/s)
Valve leakage level: DIN EN 12266 Class A
