FGNEX-Double Glass Bifacial-430W-445W

Introduction

◤
FGNEX Double glass panels (BIPV-Building Integrated Photovoltaics) are suitable for steel frame structures, which are flexible and easy to install. With beautiful appearance, and also environmentally friendly.

Feature

◤ OptimizedPower Gain

◤
High Resistance to PID;

◤
Low Risk of Micro-cracks; Zero Snail Trails Probability;

Higher-Than-Ever ROI

◤
1500-V System Voltage, Lower BOS Cost;

◤
Annual Degradation <0.5%,30-year Linear Performance Warranty;

◤
Frameless Design, Easier Surface Cleaning,

Design

◤
Unique Layout design to match the adhesive installation

◤
Unique design can meet the sunroom's requirements with excellent light transmittance and waterproof.

Working Condition

◤
Working Condition Compatibility & Safety

◤
High Resistance to High Temp, High Humidity, Sand, Acid and Alkali Environment;

◤
2400Pa Snow Loading,2400Pa Wind Loading;

◤
Class-A Fireproofing;

Parameter

ELECTRICAL CHARACTERISTICS
Model		BPDMJ72H(S)-430		BPDMJ72H(S)-435		BPDMJ72H(S)-440		BPDMJ72H(S)-445
		STC	NMOT	STC NMOT		STC	NMOT	STC	NMOT
Maximum Power at STC [Pmax]	[W]	430	321	435	325	440	329	445	333
Open Circuit Voltage [Voc]	[V]	48.79	45.6	49.01	45.8	49.29	46.0	49.54	46.3
Short Circuit Current[lsc]	[A]	11.18	9.02	11.24	9.06	11.29	9.10	11.33	9.14
Voltage at Maximum Power point[Vm]	[V]	40.47	37.2	40.76	37.4	41.06	37.7	41.33	37.9
Current at Maximum Power point[lm]	[A]	10.63	8.65	10.67	8.69	10.72	8.73	10.77	8.77
Power Tolerance	[%]	0~+3%
Module Efficiency	[%]	19.4		19.7		19.9		20.1
STC:Air Mass AM1.5,Ir-radiance 1000W/m Cell temperature 25℃. NMOT:Air Mass AM1.5,Ir-radiance 800W/mAmbient tempera-ture 20'C,wind speed 1m/s.

DOUBLE SIDES POWER OUTPUT(BACK GAIN)
5% Maximum Power	[W]	445	450	455	461
10% Maximum Power	[W]	460	465	471	476
15% Maximum Power	[W]	475	481	486	492
20% Maximum Power	[W]	490	496	502	507
Notes: Spectrum AM1.5, Irradiance Gcomp, Temperature 25℃.Gcomp=(1+AlbedoBifaciality)1000W/m2 Bifaciality=Min(lsc_rear/lsc_front,Pmpp_rear/Pmpp_front)

WORKING CONDITIONS TEMPERATURE COEFFICIENTS
Maximum System Voltage(With S)	[V]	1000 DC(IEC)
Maximum System Voltage(Without S)	[V]	1500 DC(IEC)
Operating Temperature	[℃]	-40~+85
Nominal Operating Cell Temperature	[℃]	45±3
Maximum rated current	[A]	20

Temperature Coefficient
Temperature Coefficient of Pmax	[%/℃]	-0.42
Temperature Coefficient of Voc	[%/℃]	-0.33
Temperature Coefficient of lsc	[%/℃]	0.04

MECHANICAL SPECIFICATIONS
Cell Type	Mono crystalline
Solar Cells	144(6*24)
Module Dimension [mm]	2111104630mm
Weight[Kg]	27
Front Glass [mm]	2.0 Semi tempered coated glass
Interlayer	EVA/POE/PVB
Back Glass[mm]	2.0 Semi tempered glass
Junction Box	Ip67 Rated,3 by-pass diodes
Connector	Multi-Contact MC4(or equivalent)
Frame	30mm Aluminum Frame
Maximum Load Capacity[Pa]	2400(wind load)/2400(snow load)
Package Configuration	40'HQ 770 pieces
