Pneumatic Clamp Soft Seal Butterfly Valve
Nominal Diameter:DN40~300mmFlange Size:JIS-10K、ANSI-150LbMax Operation Pressure: 1.6MPaUsing Temperature Range:-10’C~200℃Leak
Product model: D671FG
Nominal pressure: PN0.6-1.6MPa
Nominal diameter: DN50-DN300mm
Applicable temperature: -10-200 ℃
Product Material: QT450, Stainless Steel
Applicable media: ordinary acid-base, water, oil, etc
Product model: D671f-10Q/C/P
Nominal pressure: PN0.6-1.6MPa
Nominal diameter: DN50-DN300mm
Applicable temperature: -10-200 ℃
Product Material: QT450, Stainless Steel
Applicable media: ordinary acid-base, water, oil, etc
